By default, this toggle is disabled, which means that Series Defaults will be applied. Enable this toggle if you want to customize the specific series independently from others. Once enabled, the following settings will be revealed:
- Split by Legend (available if the Legend field has data)
- Display (available if Split by Legend is enabled)
- Type
- Customize Series Value Labels
- Customize Series Total Value Labels (available if the series is part of a stack or it is split by legend)
- Height Percent 1, 4
- Line Width (thickness) 1
- Outline Width 2, 3, 4
- Outline Type 1, 2, 4
- Stepped Outline 2, 3
- Outline Smoothing 2, 3
- Outline Marker 2, 3, 4
- Stack
- Cluster
- Value Axis
- Display Order
- No Data Policy
- Show in Legend
- Enabled by Default
- Show in Tooltip
- Legend Marker Shape
1 Available if the selected Type is Bars.
2 Available if the selected Type is Line.
3 Available if the selected Type is Area.
4 Available if the selected Type is Reference Line.
2 Available if the selected Type is Line.
3 Available if the selected Type is Area.
4 Available if the selected Type is Reference Line.
