Series configuration

Every series that you have added to their respective Series fields will have its own Series X Configuration section with various settings that you can use to customize their appearance and behavior independently. Each section will be named according to the number of the Series field to which the series is added (for example, Series 3 field -> Series 3 Configuration).

If the Series Configuration toggle is enabled, the specific series will be visible on the chart, but if it’s disabled, the series will not be displayed. Once enabled, you will access the following options for series customization:

Display Name
Customize This Series (reveals additional settings if enabled)
Outline Color
Outline Color Opacity
Fill Color*
Fill Color Opacity*
Conditional Formatting (reveals additional settings if enabled)
Outline Conditional Formatting* (reveals additional settings if enabled)

Settings marked by an asterisk (*) are available if the chart type is set to Column or Area.

Series Defaults are applied to all series. However, changes in any of the Series Configuration sections will override the Series Defaults if the Customize This Series toggle is enabled.
